audio

Robust dual DSP-based architecture designed for rock solid, mission critical STL audio
Linear PCM16/24 bit 32kHz, 44.1kHz, 48kHz, 96kHz sampling
Bidirectional mono, 3 mono, 6 mono, 8 mono and 16 mono connections and triple mono connections
Distributing up to 16 bidirectional channels between two codecs
Up to 8 bidirectional stereo connections.
2 stereo and 2 mono bidirectional connections
1 stereo and 4 mono bidirectional connections.
Simultaneously distributing one, two, three or six separate IP multi-unicast audio streams to up to 80 endpoints in total (Gateway-8 and Gateway-16)
Broadcasting up to 6 separate IP audio streams in multicast server mode and distributing each of these streams to unlimited endpoints over compatible IP networks.
Popular algorithms including LC-AAC, HE-AAC v1 and v2, AAC-LD, AAC-ELDv1 and v2, Opus, MPEG II, MPEG Layer-3, Tieline Music and MusicPLUS, G.722 and G.711.
Internal SSD storage as standard
Low-delay, cascade resilient aptX® Enhanced algorithm*
Optional WheatNet-IP card
Up to 8 stereo or 16 mono WheatNet-IP audio channels in/out.
Input Processing: EQ and dynamic range compressor on all inputs

Dual Gigabit (10/100/1000) Ethernet ports support automatic switching for redundancy
Dual AoIP ports for AES67 / SMPTE ST 2110-30 audio over IP streaming
Connect over Wi-Fi using USB Wi-Fi dongles*
Automated failover to backup connections.
Support for up to 4 output audio source fail over options
SmartStream PLUS dual redundant IP streaming
Fuse-IP network bonding (data aggregation)
SIP (SDP) compliant with EBU N/ACIP Tech 3326 and 3368 for interoperability with other codecs
I3P EBU Tech 3347 integration for Intercom compatibility over IP
Deterministic SIP answering and call routing: Configure up to 16 SIP accounts and connect up to 2 SIP interfaces
Selectable fixed or automatic jitter buffer: 5 automated settings available to manage network connectivity and avoid dropouts (includes configurable min and max buffer settings).
Configurable Forward Error Correction (FEC)
Highly advanced error concealment strategies
Real-time IP connection packet statistics
Real-time IP link quality displayed.
Support for Line Hunt dialing/answering and caller IDs using Tieline IP

Full hardware front panel interface including navigation, LCD display, PPM meters and dialing key pad
User-friendly HTML5 Toolbox Web-GUI enables codec configuration and control remotely over WANs
AES67 Web-GUI for configuration of AES67 and ST 2110-30 audio streams over and AES67 LAN
Toolbox Scheduler supports loading/unloading, connecting and disconnecting programs
Use the Cloud Codec Controller to configure & manage your entire codec network remotely
The TieLink Traversal Server makes dialing easy with centralized contact list management and self discovery of codecs within customized call groups*
Auto switching, dual internal AC power supplies
IPv4 & IPv6 compatible and ready
Asymmetric algorithmic encode/decode
Integrated alarm management including automatic silence detection
Low latency in-band RS-232 aux data channel
Configurable software rules engine via web-GUI for Control Port (16 GPIOs), plus WheatNet-IP LIO compatibility.
Upgrade firmware from SD card or USB sticks*
Backup and restore configuration via USB sticks
Automated firmware upgrade notifications via Web-GUI
Support for multiple languages: English, Spanish, Portuguese and French*
Backward compatible with all Tieline IP codecs

User name and password protection of codec and Toolbox HTML5 Web-GUI
Support for SSL Security Certificate installation
SIP allow lists and deny lists allow filtering of SIP URIs and User Agents.
Configuration of non-standard ports
Firewall settings to enable or disable a range of firewall-related network services, or limit ping to only work in a local subnet
Implementation of CSRF protection (Cross-Site Request Forgery)
Cloud Codec Controller supports admin and user level access to codecs with password protection
